1.Flexible Capacity Configuration
Modular battery capacity can be configured according to different household energy needs.
2.High Energy Density
Compact stackable design provides high energy capacity while saving valuable installation space.
3.Easy & Fast Installation
Stackable structure simplifies installation and system deployment, helping reduce installation time and labor costs.
4.Long Cycle Life
High-performance LiFePO₄ battery technology delivers stable operation and reliable performance for daily energy storage.
5.Reliable Home Backup Power
Provides dependable backup power for essential household loads and works well with residential solar energy systems.
Items | Parameters |
|---|---|
Battery Model | IFP-51.2V200Ah |
Nominal Voltage | 51.2V |
Typical Capacity | 200Ah |
Working Current | 150A |
Peak Current | 160±5A |
Discharge Cut-off Voltage | 40V |
Charging Voltage | 58.4V |
Standard Charging Current | 150A |
Charging Mode | Constant Current / Constant Voltage (CC/CV) |
Operating Temperature (Charge) | 0℃ ~ +45℃ |
Operating Temperature (Discharge) | -20℃ ~ +60℃ |
Communication Interface | RS485 / CAN |
Enclosure Material | Metal Shell |
Waterproof Rating | IP54 |
Weight | Approx. 130±0.5 kg |
Dimensions | 685*533*453mm |
Cycle Life | ≥2000 cycles |
